De Havilland Canada DHC-2 Beaver Aircraft Engineering Blueprints Collection
Comprehensive collection of authentic engineering drawings for the legendary DHC-2 Beaver—widely regarded as one of the finest bush aircraft ever built. This iconic Canadian design revolutionized aviation in remote areas and remains in active service worldwide over 75 years after its first flight.
Definitive Collection with Free Lifetime Updates
This is a living collection that we continuously expand. As we acquire additional Beaver documentation or drawings, we update this collection and provide free lifetime updates to all purchasers. Your one-time purchase guarantees permanent ownership and access to all future additions.
Historical Note
The DHC-2 Beaver stands as one of aviation's greatest success stories. Designed by De Havilland Canada in response to requests from bush pilots and first flown in 1947, the Beaver was purpose-built for operations in Canada's remote wilderness. Its exceptional STOL performance, rugged construction, and ability to operate from water, snow, or rough terrain made it the ultimate bush plane.
Powered by the reliable Pratt & Whitney R-985 Wasp Junior radial engine producing 450 hp, the Beaver could carry seven passengers or 1,600 lbs of cargo into and out of impossibly short strips. Its high-lift wing, full-span flaps, and powerful engine gave it a takeoff run of just 600 feet and landing roll of 500 feet—capabilities that opened vast wilderness areas to aviation.
The Beaver's all-metal construction featured a robust airframe designed to withstand the punishment of bush operations. Large doors facilitated cargo loading, and the aircraft could be equipped with wheels, floats, or skis. Over 1,600 Beavers were built between 1947 and 1967, with the majority serving with the U.S. Army and Air Force as the L-20/U-6.
Today, hundreds of Beavers remain in active service with bush operators, charter companies, and private owners worldwide. The type is prized for its reliability, versatility, and unmatched short-field performance. Many have been upgraded with turbine engines (as the Turbo Beaver), extending their service life for decades to come. The Beaver's reputation as the world's best bush plane remains unchallenged.
Blueprints Included
- Detailed engineering drawing sheets in high-quality format
- Comprehensive airframe blueprints covering all major assemblies
- All-metal construction details and structural components
- Wing assemblies and high-lift system
- Fuselage frames and monocoque structure
- Landing gear assemblies for wheels, floats, and skis
- Engine mounting and cowling details
- Control surfaces and mechanisms
- Systems and subsystems documentation
Converted from original manufacturing archives, providing quality engineering documentation for this legendary bush plane.
Engineering Standards
Documentation reflects Canadian aviation engineering standards from the late 1940s, De Havilland Canada design practices emphasizing ruggedness and field maintainability, and CAR 3 certification requirements for utility aircraft.
Format and Delivery
Digital download. High-quality files in organized format for easy navigation and reference.
Legal Notice
Provided by Online Aviation Library (Sicuro Publishing) for historical reference and research. This collection serves historians, museum professionals, restoration specialists, aerospace engineers, modelers, and researchers.
Your purchase grants permanent ownership with free lifetime updates. The compilation, structure, and presentation are © Sicuro Publishing. Underlying historical materials remain property of original creators or successors.
These drawings are for reference only. We do not guarantee completeness, accuracy, or currency. Not for current certification or repair work. For active aircraft, consult current Type Certificate holder Viking Air. Trademarks are property of respective owners.
