Tupolev Tu-214 — Technical Documentation Collection

The Tupolev Tu-214 is a medium-haul, narrow-body passenger aircraft manufactured by the Kazan Aviation Plant (KAP). Powered by two Aviadvigatel PS-90A turbofan engines and seating up to 210 passengers, it is one of Russia's most capable commercial transports — and one of the most technically documented. This collection brings together 33 primary-source documents across three major manual sets: the Aircraft Maintenance Manual (РТЭ), the Flight Operations Manual (РЛЭ), and the PS-90A Engine Maintenance Manual — sourced from registered factory copies and digitized for the serious researcher, restorer, and aviation professional.

Please note: the documents in this collection are static documents. They represent the state of knowledge at the time of their original publication and have been digitized and cataloged as historical and technical reference material. They are not live regulatory publications and do not substitute for current airworthiness directives or type certificate data.

Key Technical Data

• Powerplant: 2 × Aviadvigatel PS-90A turbofan — 16,000 kgf static thrust (17,600 kgf emergency); ICAO Chapter 3 compliant
• MTOW: 110,750 kg  |  Max Payload: 25,200 kg  |  Empty Weight: ~59,000 kg
• Max Fuel Capacity: 35,710 kg (with ventral tank)
• Cruising Speed: 810–850 km/h (Mach 0.8)  |  Test Speed: 970 km/h at 10,000 m
• Range at Max Payload: 3,800–4,340 km  |  Max Range: 5,650–6,500 km
• Capacity: Up to 210 passengers (single-class)
• Autopilot: Integrated digital flight & navigation system — ICAO CAT II/III automatic approaches and landings
• Winglets: ~2.2% aerodynamic efficiency gain; 500–600 kg fuel saving on max-range flights

Sub-Collection A — PS-90A Engine Maintenance Manual

Двигатель ПС-90А — Руководство по Технической Эксплуатации · Ref: 94-00-807 РЭ · 1990 · Language: Russian

6 documents:

• Book 1, Part 1 — Sections 072.00.00, 070.00.00
• Book 1, Part 2 — Sections 072.50.00…070.00.05
• Book 2 — Section 073.00.00
• Book 2, Part 2 — Sections 073.21.00–073.28.00
• Book 3 — Sections 075.00.00, 077.00.00, 080.00.00
• Electrical Schematics — Sections 073.14.01, 077.00.00, 077.00.01

Sub-Collection B — Tu-214 Flight Operations Manual (РЛЭ)

Самолёт Ту-214 — Руководство по Лётной Эксплуатации · ОАО "Туполев" · Approved: ДЛС ГСГА Минтранса России · 25 December 2000 · Language: Russian

5 documents:

• Book 1 — First Edition · 2000
• Book 2 — First Edition · 2000
• Appendix (Приложение) — First Edition · 2000
• Supplement No. 2 (Дополнение №2) — for aircraft Nos. 64502, 64503 (160-seat configuration) · 2002
• Temporary Amendment No. 23 + Amendment No. 2 — signed Chief Designer И.С. Кабатов · 10 July 2003

Sub-Collection C — Tu-214 Aircraft Maintenance Manual (РТЭ)

Самолёт Ту-214 — Руководство по Технической Эксплуатации · Approved: Департамент ГС ГА Минтранса России · 21 May 2001 · Registration Copy: Учтен. экз. № 25 · Language: Russian

22 documents:

• Sections 001, 004, 005, 006, 007, 008, 009, 010, 011, 020 — General / Airframe
• Section 012
• Section 021 · 1993
• Sections 022, 027 Part 1 · 2000
• Sections 023, 182 · 1993
• Section 024 · 1997
• Section 025 · 1993
• Sections 026, 028, 049 · 1993
• Section 027 Part 2
• Section 029
• Sections 030, 035
• Section 031 · 1997
• Section 032 · 1993
• Section 033 · 1995
• Sections 034, 142 · 1993
• Section 038 · 1996
• Sections 051, 052, 053, 054 · 1993
• Sections 055, 056, 057 · 1993
• Sections 071, 076, 077, 078, 079, 080 · 1993
• Section 110 — ACAS-II Collision Avoidance System · 2000
• Section 113 · 1995
• Section 144 · 1997

Living Collections with Free Lifetime Updates — Please review our Disclaimer and Export Notice before purchasing.
