North American T-28 Trojan - Aircraft Manuals Collection

This comprehensive digital collection contains authentic technical manuals for the North American T-28 Trojan, one of the most successful and widely-used military training aircraft in aviation history. These original military publications provide operational, maintenance, structural repair, and parts information for multiple variants of this legendary trainer.

Definitive Collection with Free Lifetime Updates: This is a living collection that we continuously expand and refine. As we acquire additional T-28 Trojan documentation, technical bulletins, or variant-specific materials, we update this collection and provide free lifetime updates to all purchasers. Your one-time purchase guarantees access to all future additions and improvements to this collection.

Historical Note

The North American T-28 Trojan holds a distinguished place in aviation history as one of the most successful military training aircraft ever produced. Designed in the late 1940s to replace the venerable T-6 Texan, the T-28 represented a significant leap forward in trainer aircraft technology, bridging the gap between piston-engine trainers and the emerging jet age.

Development began in 1946 when North American Aviation responded to a U.S. Air Force requirement for an advanced trainer capable of preparing pilots for the transition to high-performance fighters. The prototype XT-28 first flew on September 26, 1949, powered by an 800-horsepower Wright R-1300 radial engine. The aircraft's design incorporated lessons learned from WWII training programs, featuring a tandem cockpit configuration, tricycle landing gear, and handling characteristics that closely mimicked operational fighters of the era.

The T-28A entered USAF service in 1950 and quickly proved its worth as a primary advanced trainer. With its powerful 800-hp engine, the T-28A could reach speeds of 283 mph and offered student pilots experience with retractable landing gear, variable-pitch propellers, and more complex systems than previous trainers. Between 1950 and 1957, the Air Force acquired 1,194 T-28A aircraft, which became the backbone of advanced pilot training programs throughout the 1950s and early 1960s.

The U.S. Navy recognized the T-28's potential and ordered a more powerful variant, the T-28B, equipped with a 1,425-horsepower Wright R-1820 engine. First flown in 1953, the T-28B featured strengthened airframe components, improved systems, and carrier-capable modifications. The Navy procured 489 T-28B aircraft, followed by 299 T-28C models specifically designed for carrier landing training with full arresting gear. These aircraft served as the Navy's primary advanced trainer well into the 1980s, training thousands of naval aviators.

Beyond its training role, the T-28 demonstrated remarkable versatility in combat operations. During the 1960s, the aircraft was extensively modified for counter-insurgency (COIN) operations in Southeast Asia. The T-28D variant, armed with machine guns, rockets, and bombs, served with distinction in Vietnam and Laos, providing close air support and ground attack capabilities. These armed Trojans flew thousands of combat missions, proving that the robust airframe could excel in roles far beyond its original training mission.

Production totaled approximately 1,948 aircraft across all variants between 1950 and 1957. The type remained in active U.S. military service until 1984, when the last Navy T-28s were finally retired after more than three decades of service. The T-28's international service included France, South Vietnam, Laos, Thailand, the Philippines, Argentina, and many other nations. Today, hundreds of T-28s remain active in the civilian warbird community, delighting airshow audiences worldwide.

Manuals Included in This Collection

• Flight Manual - USAF Series T-28A Aircraft - T.O. 1T-28A-1, October 1970/December 1972
• Flight Operating Instructions Handbook - USAF Series T-28A Aircraft - AN 01-60FGA-1, April 1951/October 1951
• Illustrated Parts Breakdown Technical Manual - T-28A and T-28D Aircraft - T.O. 1T-28A-4, June 1952/September 1963
• Illustrated Parts Breakdown Technical Manual - T-28A Aircraft - T.O. 1T-28A-4, June 1952/May 1972
• Maintenance Technical Manual - USAF Model T-28A Aircraft - T.O. 1T-28A-2, June 1958/July 1959
• Structural Repair Technical Manual - T-28A, T-28B, T-28C & AT-28D Aircraft - T.O. 1T-28A-3, October 1958/July 1973
• NATOPS Flight Manual - Navy Model T-28B/C Aircraft - NAVAIR 01-60FGB-1, May 1966/January 1981
• NATOPS Pilot's Pocket Checklist - T-28B/C Aircraft - NAVAIR 01-60FGB-1B, December 1972

This collection provides comprehensive coverage of USAF (T-28A, T-28D) and Navy (T-28B, T-28C) variants. Documentation spans from 1951 through 1981, covering the aircraft's entire operational service period with both USAF Technical Orders and Navy NAVAIR/NATOPS manuals.

Engineering Norms and Standards

The T-28 Trojan was developed and certified under U.S. Air Force and Navy military specifications of the late 1940s and 1950s. The aircraft incorporated advanced features for its era including all-metal stressed-skin construction, hydraulically-operated retractable landing gear, and Wright radial engines (R-1300 for T-28A, R-1820 for T-28B/C). Technical Orders (TO) and NATOPS manuals reflect military airworthiness standards, maintenance procedures, and standardized operating procedures that governed military flight training operations during the Cold War era.

Format and Delivery

All manuals are provided as high-resolution PDF files, optimized for both screen viewing and printing. Files are organized in a clear folder structure by variant and manual type. Instant download delivery upon purchase completion.

Disclaimer

This item is sold for historical and reference only. These are either ORIGINAL or COPIES of manuals and blueprints used when these aircraft were in active duty, now transferred into electronic format. These manuals and blueprints are not meant to be used for current update material for certification / repair, but make an excellent reference for the scholar, collector, modeller or aircraft buffs. For proprietary reasons, we generally only provide civil manuals and blueprints on obsolete aircraft / engines / helicopter. The information is for reference only, and we do not guarantee the completeness, accuracy or currency of any manuals.

Reference herein to any specific commercial products by trade name, trademark, manufacturer, or otherwise, is not meant to imply or suggest any endorsement by, or affiliation with that manufacturer or supplier. All trade names, trademarks and manufacturer names are the property of their respective owners.
