Luftwaffe Phantom II — GAF F-4F & RF-4E Flight Documentation Collection

3 Primary-Source Documents | German Air Force (Luftwaffe) | 1975–1991

The F-4F Phantom II was the Luftwaffe's frontline air superiority fighter for over three decades — a purpose-built, lightweight variant of the F-4E developed exclusively for West Germany, stripped of the internal fuel cell and target identification system to save 3,300 lbs, fitted with maneuvering slats for superior high-AOA tracking, and later upgraded under the ICE program with APG-65 digital radar and AIM-120 AMRAAM capability.

This collection presents three original German Air Force (GAF) primary-source flight documents — two published under authority of the U.S. Air Force for the Luftwaffe, one issued directly by the Bundesminister der Verteidigung — covering the F-4F fighter variant and the RF-4E reconnaissance variant as operated by the Materialamt der Luftwaffe.

Document Manifest — 3 GAF Publications

1. GAF TO 1F-4F-1 — Flight Manual, GAF Series F-4F Aircraft
   McDonnell Aircraft · Published under authority of the Secretary of the U.S. Air Force
   15 October 1975 · Change 2: 15 July 1976
   Contracts: N00019-72-C-0180 · F33657-73-C-0305
   Covers aerodynamic performance, engine parameters (J79-GE-17A), stability augmentation, high-AOA handling, stall warning systems, and full GAF-specific flight envelope data including Mach 2.23 performance at 36,000 ft.
2. GAF TO 1F-4F-34-1 — Aircrew Weapons Delivery Manual, Volume 1, GAF Series F-4F Aircraft
   McDonnell Aircraft · Published under authority of the Secretary of the U.S. Air Force
   15 September 1976 · Supersedes GAF TO 1F-4F-34-1 Vol.1 dated 15 March 1973, Changes 1–7
   Augmented by: GAF TO 1F-4F-34-1A and GAF TO 1F-4F-34-1, Volume 2
   Covers all weapons delivery modes, stores configurations, and aircrew procedures for the GAF F-4F in the air superiority and ground attack roles.
3. GAF T.O. 1F-4(R)E-1 — RF-4E Flight Manual
   Materialamt der Luftwaffe / Führungsstab der Luftwaffe (FüL)
   Published under authority of the Bundesminister der Verteidigung
   1 January 1982 · Change 8: 1 October 1991 · DSK: L7001200717
   MetALw/Dv-Stelle · Beleg-Nr.: 1812/92
   Covers the RF-4E reconnaissance variant as operated by the Luftwaffe through the ICE-era upgrades, including all flight procedures, systems, and operational parameters under Bundeswehr authority.

Technical Highlights

• Wing: Low-mounted 45° swept-back with 5° dihedral outer panels and 23° anhedral all-moving stabilator
• Leading edge maneuvering slats for superior high-AOA tracking and reduced stall speed
• Dual J79-GE-17A turbojets: 11,810 lbf dry · 17,900 lbf with afterburner per engine
• Three-axis Pitch/Roll/Yaw Stability Augmentation System (SAS)
• Stall warning: pedal shaker engages at 22.3 units AOA · Full separation at 26–30 units
• Maximum speed: Mach 2.23 at 36,000 ft clean configuration
• Weight reduction vs F-4E: ~3,300 lbs saved by removing fuel cell #7 and target ID system
• ICE upgrade: APG-65 digital radar · AIM-120 AMRAAM integration

Who This Collection Is For

Luftwaffe veterans and historians. Cold War aviation researchers. Scale modelers requiring primary-source GAF configuration data. Museum curators and Phantom restoration teams. Defense analysts studying NATO air superiority doctrine. Collectors of German aviation primary-source documentation.

This is an archival, static-copy edition fixed at its original publication date. Intended for historical reference, flight simulation, museum restoration, and educational use only. Not approved for active airworthiness maintenance under FAA 14 CFR § 43.13, EASA Part-M, or equivalent international regulations. Operators of active aircraft must use current, revision-controlled publications from the Type Certificate holder or an authorized distributor.
