Junkers Jumo 205 — Engine Manuals Collection
A curated collection of 13 primary-source factory documents covering the Junkers Jumo 205 — the most successful aviation diesel engine in history — variants B, C, and D. All documents are in German language.
Designed by Junkers Motorenbau GmbH and evolved from the Jumo 204, the Jumo 205 used a revolutionary opposed-piston two-stroke diesel design offering exceptional fuel economy for long-range operations. It powered the Junkers Ju 86, Blohm & Voss BV 138, Dornier Do 18, Do 26, and Focke-Wulf A 17. Over 900 units were produced between 1934 and 1943.
Variant C / D — 6 Manuals
-
Jumo 205 C/D Operation and Maintenance — 4 documents:
– Jumo 205 C Series 4 Diesel Aircraft Engine Operating Instructions and Maintenance Manual — Betriebsanweisung und Wartungsvorschrift (German Language)
– Jumo 205 C Series 4 Diesel Aircraft Engine Operating and Maintenance Manual Cover — Betriebsanweisung und Wartungsvorschrift (German Language)
– Jumo 205 D Series 1 and 2 Diesel Aircraft Engine Operating Instructions and Maintenance Manual — Betriebsanweisung und Wartungsvorschrift (German Language)
– Jumo 205 C Series 4 Diesel Aircraft Engine Abridged Operating and Maintenance Guide — Kurz-Betriebs- und Wartungsanweisung (German Language) -
Jumo 205 C/D Illustrated Parts Catalog
Jumo 205 C Aircraft Engine – Illustrated Parts Catalog — Ersatzteilliste (German Language) -
Jumo 205 C/D Brochures & Training Material
Jumo 205 C, D and Jumo 207 B Aircraft Engine Instructional Training Manual — Lehr-Vortrag (German Language)
No-Variant Manuals — 7 Manuals
-
Jumo 205 Operating Instructions
Jumo 205 Diesel Aircraft Engine Operating Instructions Manual 1936 — Betriebs-Anweisung (German Language) -
Jumo 205 Engine Maintenance — 2 documents:
– Jumo 205 Diesel Aircraft Engine Maintenance Chart and Specifications — Wartungs-Tafel und Kennwerte, Junkers-Motorenbau GmbH Edition (German Language)
– Jumo 205 Diesel Aircraft Engine Maintenance Chart and Specifications — Wartungs-Tafel und Kennwerte, JFM AG Edition (German Language) -
Jumo 205 Technical Publications — 2 documents:
– Jumo 205 Heavy-Oil Aero Engine Special Offprint Report — Zahlenwunder im Junkers-Schweroel-Flugmotor (German Language)
– Jumo 205 Heavy-Oil Aero Engines Long-Distance Aircraft Technical Report — Schweroel-Flugmotoren (German Language) -
Jumo 205 Brochures & Training — 2 documents:
– Jumo 205 Diesel Aircraft Engine Promotional Brochure — Junkers-Schweroel-Flugmotor (German Language)
– Jumo 205 Diesel Aircraft Engine Training Material for Technical Flight Schools — Lehrmittel für technische Fliegerschulen (German Language)
Historical Background
Designed by Junkers Motorenbau GmbH and evolved from the Jumo 204, the Jumo 205 was the definitive opposed-piston diesel aero engine. Its key variants:
- Jumo 205C — Early main production model, 600 hp
- Jumo 205D — Military version optimized for higher RPM, 880 hp
- Jumo 205E — Civil version, 700 hp
- Jumo 207 — High-altitude variant with turbo-supercharger, up to 1,000 hp
Post-war, its opposed-piston design directly inspired the British Napier Deltic engine used in Royal Navy fast patrol boats and British Rail locomotives.
Technical Specifications
- Type: Inline diesel — opposed-piston, two-stroke
- Configuration: 6 cylinders, 12 opposed pistons, two crankshafts
- Displacement: 16.62 litres (1,014 cu in)
- Bore × Stroke: 105 mm × 2 × 160 mm
- Compression Ratio: 17:1
- Power Output: 550 – 880 hp
- Dry Weight: 510 kg (1,124 lbs)
- Fuel: Commercial diesel (gasoil)
Notable Engineering Features
- Two pistons per cylinder moving toward each other — no cylinder head
- Two crankshafts linked by reduction gears
- No intake or exhaust valves — uses ports in cylinder walls
- Dual injection pumps per cylinder
- Exceptional fuel economy enabling record-breaking long-range flights
