The Heinkel He 51 was the Luftwaffe's first standard single-seat biplane fighter, designed by Walter and Siegfried Günter and powered by the BMW VI 7.3Z liquid-cooled V12 engine. This collection brings together six original German-language technical documents covering the C and D variants — the dedicated ground-attack and operational refinement marks that saw service in Spain and beyond.
Definitive Collection with Free Lifetime Updates: This is a living collection that we continuously expand and refine. As we acquire additional He 51 documentation, technical bulletins, or variant-specific materials, we update this collection and provide free lifetime updates to all purchasers. Your one-time purchase guarantees access to all future additions and improvements to this collection.
Historical Note
The He 51 emerged from the clandestine German rearmament programme of the early 1930s, first flying in 1933 and entering Luftwaffe service in 1935 as the service's inaugural standard fighter. A conventional single-bay all-metal biplane with fabric covering and N-type interplane struts, it was praised for its light controls, low wing loading, and exceptional turn radius. The BMW VI 7.3Z V12 delivered 750 hp, giving the aircraft a maximum speed of 330 km/h at sea level. The He 51C-1 introduced underwing racks for four 50 kg bombs, transitioning the type into a ground-attack role during the Spanish Civil War with the Legion Condor. Though outclassed by monoplane fighters by 1937, the He 51 remained in training and ground-attack roles through the early war years. Variants ranged from the initial A-1 through the floatplane B-2 to the C and D ground-attack marks covered in this collection.
Manuals Included in This Collection
Variant C-D (4 Manuals)
- He 51 C-D Aircraft Handbook — He 51 C und D Flugzeug-Handbuch (German Language)
- He 51 C-D Aircraft Description Manual — He 51 C und D Flugzeug-Beschreibung (German Language)
- He 51 C-D Armament Technical Manual — He 51 Bewaffnung LDv 580 (German Language)
- He 51 C-D Flight Operating Instructions — Bedienungsvorschrift Fl (German Language)
No-Variant Manuals (2 Manuals)
- MG 17 Machine Gun Operating Instructions Part 1 — MG 17 Teil 1 (German Language)
- Revi 3a and 3b Reflex Viewfinder Operating Instructions — Bed.-Vorschrift LDv 103 (German Language)
Six documents spanning aircraft structure, flight operations, armament systems, and weapons sighting — the core technical library for the He 51 C and D marks as issued to Luftwaffe ground crews and pilots.
Engineering Norms and Standards
The He 51 was designed and built to Reichsluftfahrtministerium (RLM) engineering standards of the mid-1930s, with documentation issued under the Luftdienstvorschrift (LDv) system. The BMW VI 7.3Z engine operated to military power ratings with glycol cooling and a two-bladed metal propeller. Standard armament comprised two 7.92 mm MG 17 machine guns above the engine with 500 rounds each, with the C-1 adding four 50 kg bomb racks. Empty weight was 1,460 kg; loaded weight 1,900 kg. Service ceiling reached 7,700 m with a range of 570 km on internal fuel.
Format and Delivery
Instant digital download. All documents are supplied as high-resolution PDFs, optimised for screen reading and print. Files are clearly named and organised by variant and document type. Compatible with all PDF readers on desktop, tablet, and mobile.
Disclaimer
These documents are provided for historical reference and research purposes only. They reflect engineering and operational standards of their original publication dates. No guarantee is made as to completeness or accuracy for any current application. All trade names and designations remain the property of their respective owners. Copyright © Sicuro Publishing.
