Fiat Aviazione RS.14 — Primary-Source Documentation Collection
The Fiat R.S.14 (Ricognitore Stiavelli 14) was Italy’s principal long-range maritime strategic reconnaissance seaplane of the Second World War. Designed by engineers Manlio Stiavelli and Lucio Lazzarino at Fiat’s CMASA subsidiary in Marina di Pisa, the RS.14 combined an exceptionally clean aerodynamic fuselage with twin Fiat A.74 radials to achieve a 2,500 km operational range over open water. This collection assembles the three primary factory documents covering the airframe and its powerplant.
Aerodynamic Reports & Structural Design
- Fuselage Drag Optimization: All-metal stressed-skin cantilever low/mid-wing monoplane with a well-glazed nose section for bombardier-observers, designed to minimize airflow detachment.
- Wing & Surface Materials: Duralumin-framed ailerons and flaps sheathed in varnished canvas to minimize weight and balance the aerodynamic center of pressure.
- Parasitic Float Drag: Two large metallic undercarriage floats linked to engine nacelles and fuselage via struts and brace wires introduced significant parasitic drag, limiting top speed despite the clean fuselage.
Engine Technical Notes — Fiat A.74 R.C.38
- Powerplant: Twin wing-mounted Fiat A.74 R.C.38 — 14-cylinder double-row air-cooled radial, 840 hp (626 kW) per engine at 3,800 m rated altitude.
- Propellers: Three-blade metal variable-pitch. Early prototypes evaluated counter-rotating propellers to cancel structural torque during calm-water takeoff runs.
- Nacelle Sub-systems: Engineering bulletins dictated that remote-controlled defensive weapon stations could be nested directly into the rear profiles of the engine nacelles.
Handling & Stability Studies
- Air Handling (May 1939): Flight testing confirmed excellent overall handling and maneuverability in clear air, surpassing initial military design expectations.
- Hydrodynamic Instability: Severe challenges in rough sea states — structural instability when confronting heavy waves made open-sea rescue deployments hazardous.
- Structural Weakness: Float struts and vertical mounting assemblies proved fragile under repeated hard water landings, causing structural warping. A two-year modification period was required before frontline clearance.
Performance Data
| Parameter | Value |
|---|---|
| Crew | 4–5 (Pilot, Co-pilot, Wireless Operator, Bombardier/Observer) |
| Wingspan | 19.54 m (64 ft 1 in) |
| Length | 14.10 m (46 ft 3 in) |
| Empty Weight | 5,410–5,470 kg (11,927–12,059 lbs) |
| Max Loaded Weight | 8,470 kg (18,673 lbs) |
| Maximum Speed | 378–390 km/h at 4,000 m |
| Cruising Range | 2,500 km (1,553 miles) |
| Service Ceiling | 6,000–6,300 m (19,685–20,669 ft) |
| Climb to 5,000 m | 15–17.1 minutes |
Engineering Bulletins & Technical Notes
The primary factory document — C.A. 578/2 (1943) — covers complete blueprints for rigging the float struts, adjusting cable tensions on canvas flight surfaces, installing the ventral bomb bay pod (up to 400 kg depth charges), and servicing the Fiat A.74 radials. The RS.14 entered frontline service in early 1942 after a two-year structural modification program.
Collection Manifest
Total Manuals: 3
- RS.14 Operating & Maintenance: Idrovolante Fiat R.S.14 (Serie IIIª) — Istruzioni e Norme per il Pilotaggio, il Montaggio, la Regolazione e la Manutenzione — C.A. 578/2 — Ministero dell’Aeronautica, Direzione Generale delle Costruzioni e degli Approvvigionamenti — 1943 — Italian Language
- RS.14 Engine — Operating Instructions: Motore Fiat A74 RC 38 e Derivati — Istruzioni per l’Uso del Motore — C.A. 400 — Fiat, Ufficio Tecnico Motori Aviazione, Torino — Italian Language
- RS.14 Engine — Illustrated Parts Catalogue: Catalogo Nomenclatore per Motore Fiat A74 RC 38 S e Derivati — Fiat S.A., Ufficio Pubblicazioni Tecniche Motori Aviazione, Torino — Italian Language
