Breguet Br.1150 Atlantic — Flight Manual & Flight Handbook, Multi-Operator Edition
€45,00

Breguet Br.1150 Atlantic — Flight Manual & Flight Handbook, Multi-Operator Edition

The Breguet Br.1150 Atlantic was the definitive Western European maritime patrol and anti-submarine warfare (ASW) aircraft of the Cold War era — purpose-built to a 1958 NATO specification and operated by France, the Netherlands, Germany, and Italy. Designed by the Société Anonyme des Ateliers d'Aviation Louis Breguet and managed through the multinational SECBAT consortium, the Atlantic combined an 18-hour mission endurance, a 9,000 km range, and a double-bubble pressurized fuselage with a dedicated unpressurized 9-metre weapons bay — a configuration that set the standard for NATO maritime patrol operations for three decades. This collection brings together five primary-source flight manuals from three distinct operators, spanning from the original 1964 manufacturer's handbook to the 1987 German Luftwaffe change-incorporated edition.

Document Manifest — 5 Primary-Source Documents

1. Atlantic 1150-03 Flight Handbook — Volume 1
Reference: Atlantic 1150-03 | Publisher: S.A. des Ateliers d'Aviation Louis Breguet, 24 Rue Georges-Bizet, Paris XVIe
Issue: No. 1, January 1964
Language: English
The original manufacturer's flight handbook issued directly by Breguet at first delivery. Dark navy cover with gold NATO compass rose emblem and aircraft line drawing. The foundational reference document for all subsequent operator-specific manuals.

2. Atlantic 1150-03 Flight Handbook — Volume 2
Reference: Atlantic 1150-03 | Publisher: S.A. des Ateliers d'Aviation Louis Breguet, 24 Rue Georges-Bizet, Paris XVIe
Issue: No. 1, January 1964
Language: English
Volume 2 of the original manufacturer's handbook, completing the full Breguet-issued flight reference set.

3. Flight Manual BR1150/SP-13A — Volume 1
Reference: MLD 1U–BR1150-1, Volume 1 | Publisher: Royal Netherlands Navy (Koninklijke Marine) — Bureau Vliegtuigen en Vliegtechnische Aangelegenheden
Authority: Uitgegeven in opdracht van het Hoofd van het Bureau Vliegtuigen en Vliegtechnische Aangelegenheden
Base Date: 1 April 1976 | Change 4: 1 March 1982 | Number of Copies: 100
Replaces: UCB-AN 104 / T-UCB-AN 104 for the Royal Netherlands Navy
Language: English
The Dutch MLD operator's flight manual for the BR1150/SP-13A variant. Change 4 incorporated. Incomplete without classified supplements GAF T.O. 1U–BR1150-1A and GAF T.O. 1U–BR1150-1B.

4. Flight Manual BR1150/SP-13A — Volume 2
Reference: MLD 1U–BR1150-1, Volume 2 | Publisher: Royal Netherlands Navy (Koninklijke Marine)
Base Date: 1 April 1976 | Change 4: 1 March 1982 | Number of Copies: 100
Language: English
Volume 2 of the Dutch MLD operator's flight manual, completing the two-volume Royal Netherlands Navy set.

5. Flight Manual BR1150 — Volume 1
Reference: GAF T.O. 1U–BR1150-1, Volume 1 | Publisher: Materialamt der Luftwaffe — Führungsstab der Luftwaffe (Fü L)
Authority: Published under authority of the Bundesminister der Verteidigung
DSK: L7001201355 | DW 150 | Base Date: 1 March 1985 | Change 1: 1 August 1987
Language: German / English
The German Luftwaffe operator's flight manual for the BR1150. Consists of Volumes 1 and 2; incomplete without classified supplements GAF T.O. 1U–BR1150-1A, 1B, 1C, 1D and all Flight Crew Checklists. Operational Supplement GAF T.O. 1U–BR1150-1S-68 remains effective.

Aircraft Technical Profile

Aerodynamic Configuration

  • Type: Mid-wing monoplane, twin turboprop, long-range maritime patrol
  • Fuselage: Double-bubble cross-section — pressurized upper lobe (12-man crew) / unpressurized lower lobe (9 m weapons and sonobuoy bay)
  • Wing Span: 37.42 m — high-aspect-ratio for low-speed patrol efficiency
  • Sensor: Retractable under-fuselage radome (minimizes parasite drag in transit)

Powerplant

  • Engines: 2 × Rolls-Royce Tyne RTy.20 Mk 21 two-spool turboprop
  • Power: 6,100 eshp (4,500 kW) per engine
  • Propellers: Four-blade variable-pitch fully feathering de Havilland
  • Fuel: 23,120 litres internal; single-engine shutdown technique used for extended loiter

Performance Data

  • Maximum Speed: 648 km/h (350 kt) at altitude
  • Patrol Loiter Speed: 315 km/h (170 kt)
  • Stall Speed (full flap): 167 km/h (90 kt)
  • Maximum Range: 9,000 km (4,900 nm)
  • Maximum Endurance: 18 hours
  • Service Ceiling: 9,145 m (30,000 ft)
  • Rate of Climb: 14.7 m/s (2,890 ft/min) at sea level
  • Takeoff Distance (MTOW): 1,620 m

This is an archival, static-copy edition fixed at its original publication date. Intended for historical reference, flight simulation, museum restoration, and educational use only. Not approved for active airworthiness maintenance under FAA 14 CFR § 43.13, EASA Part-M, or equivalent international regulations. Operators of active aircraft must use current, revision-controlled publications from the Type Certificate holder or an authorized distributor.

⚠️ Regulatory Notice: Under FAA 14 CFR § 43.13 and EASA Part-M, any mechanic performing maintenance on an active aircraft must use current, manufacturer-approved revision-controlled data. This archival document does not satisfy that requirement.

Living Collections with Free Lifetime Updates — Please review our Disclaimer and Export Notice before purchasing.
