  • Das Großflugboot BV 222 Wiking - Luftwissen 1944 Cover Page
  • BV 222 V2 Bedienungsvorschrift-FL - Text Only Cover Page
  • BV 222 V2 bis V6 Bedienungsvorschrift-Fl - Text Only Cover Page
  • BV 222 V1 Erster Einsatz - Operational Report Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 0 - Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 1 Boot - Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 9A Allgemeine Ausrüstung - Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 8A Schußwaffenanlage - Cover Page
  • BV 222 A Kennblatt - E-Stelle Travemünde Cover Page
  • BV 222 Wiking LB4 Banner 1
  • BV 222 Wiking LB4 Banner 2
  • BV 222 Wiking Promotional Banner
  • BV 222 Wiking Standard Cover Page
  • BV 222 Bramo 323 R2 Cover Page - Text Only
  • Das Großflugboot BV 222 Wiking - Luftwissen 1944 Cover Page
  • BV 222 V2 Bedienungsvorschrift-FL - Text Only Cover Page
  • BV 222 V2 bis V6 Bedienungsvorschrift-Fl - Text Only Cover Page
  • BV 222 V1 Erster Einsatz - Operational Report Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 0 - Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 1 Boot - Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 9A Allgemeine Ausrüstung - Cover Page
  • BV 222 C Flugzeug-Handbuch Teil 8A Schußwaffenanlage - Cover Page
  • BV 222 A Kennblatt - E-Stelle Travemünde Cover Page
  • BV 222 Wiking LB4 Banner 1
  • BV 222 Wiking LB4 Banner 2
Blohm & Voss BV 222 Wiking — Maintenance & Technical Manuals · WWII Flying Boat Documentation · Digital Download
€89,00

A structured digital archive of primary technical documentation for the Blohm & Voss BV 222 Wiking — the largest operational flying boat of World War II. This collection covers all three principal variants (A, C, V) across 11 original documents, including factory handbooks, flight operating instructions, technical reports, and a rare photographic series.

Definitive Collection with Free Lifetime Updates: This is a living collection that we continuously expand and refine. As we acquire additional BV 222 Wiking documentation, technical bulletins, or variant-specific materials, we update this collection and provide free lifetime updates to all purchasers. Your one-time purchase guarantees access to all future additions and improvements to this collection.

Historical Note

The Blohm & Voss BV 222 Wiking originated in 1937 as a Lufthansa commission for a long-range transatlantic commercial flying boat capable of carrying 24 passengers in sleeping berths between Europe and North America. The outbreak of war in 1939 halted commercial development, and the completed prototypes were pressed into Luftwaffe service as long-range maritime transport and reconnaissance platforms.

The BV 222 was the largest flying boat to see operational service during the war. Its 46-metre wingspan housed a hollow wing spar through which crew members could physically crawl to access overwing defensive gun turrets during flight. The spacious hull, originally designed for passenger comfort, proved equally effective for carrying troops, supplies, and casualties across the Mediterranean and Atlantic theatres.

Two distinct powerplant configurations defined the production history. Early prototypes (V1–V6, V8) used six Bramo Fafnir 323R-2 nine-cylinder air-cooled radial engines producing 1,000 hp each, giving the A-variant a maximum speed of 385 km/h and a range of 3,100 km. Later production aircraft (V7 and the C-0 series) were re-engined with six Junkers Jumo 207C liquid-cooled, opposed-piston, two-stroke diesel engines — extending operational range to 6,100 km and enabling refuelling at sea from U-boats for sustained Atlantic reconnaissance.

A total of 13 aircraft were completed. BV 222s flew supply missions to Rommel's Afrika Korps, evacuated wounded from North Africa, and conducted long-range maritime reconnaissance over the Atlantic. Post-war, surviving aircraft were evaluated by both the US Navy and the Royal Navy. British test pilot Captain Eric "Winkle" Brown flew captured examples — though poor engine reliability plagued testing, with the US-captured V2 suffering four engine fires in just 38 minutes of flight. No BV 222 survives today.

Manuals Included in This Collection

Variant A

  • Bv 222 A Technical Reports & Certificates
  • Bv 222 A Identification Sheet, Kennblatt (German language)

Variant C

  • Bv 222 C Aircraft Handbook
  • BV-222 C Aircraft Handbook Part 0 — General Information, 1943 / Flugzeug-Handbuch Teil 0 Allgemeine Angaben (German language)
  • BV-222 C Aircraft Handbook Part 1 — Boat / Flugzeug-Handbuch Teil 1 Boot (German language)
  • BV-222 C Aircraft Handbook Part 8A — Push Weapon System / Flugzeug-Handbuch Teil 8A Schubwaffenanlage (German language)
  • BV-222 C Aircraft Handbook Part 9A — General Equipment / Flugzeug-Handbuch Teil 9A Allgemeine Ausrüstung (German language)

Variant V

  • Bv 222 V Flight Manual
  • Bv 222 V2 Flight Operating Instructions Manual / Bedienungsvorschrift Fl (German language)
  • Bv 222 V2 bis V6 Flight Operating Instructions Manual / Bedienungsvorschrift Fl (German language)
  • Bv 222 V Technical Reports & Certificates
  • BV 222 V1 First Operational Use Report / Erster Einsatz (German language)

Non-Variant Documents

  • BV 222 Systems
  • BV 222 Dual-Fuel System Operating Card / Bedienungs-Karte für Zweistoffanlage (German language)
  • BV 222 Series of Photographs
  • The Large Flying Boat BV 222 Wiking / Das Großflugboot BV 222 Wiking (German language)

This collection spans the full production arc of the BV 222 programme — from the radial-engine V-series prototypes through the diesel-powered C-0 production aircraft — providing variant-specific coverage across flight operations, hull engineering, weapons systems, general equipment, and systems documentation.

Engineering Norms and Standards

The BV 222 was designed and built under Reichsluftfahrtministerium (RLM) engineering standards and Luftwaffe airworthiness requirements of the late 1930s and early 1940s. Key engineering characteristics documented in this collection include:

  • Hull hydrodynamics: Unfaired lateral main step followed by five secondary steps and a knife-edge terminal keel — optimised for open-sea operations and rough-water takeoffs
  • Structural design: Closely spaced bulkheads below the cabin floor for hull integrity; open interior above for maximum payload volume
  • Wing spar access: Hollow 46-metre spar allowing in-flight crew access to overwing defensive positions
  • Dual-fuel system: Documented in the Bedienungs-Karte für Zweistoffanlage, enabling operation across both radial and diesel powerplant variants
  • Powerplant engineering: Bramo Fafnir 323R-2 radial (1,000 hp, nine cylinders) and Junkers Jumo 207C opposed-piston two-stroke diesel
  • Performance envelope: Max speed 385–390 km/h; cruise 257–344 km/h; service ceiling 7,300 m; MTOW up to 49,000 kg (C-variant)

Format and Delivery

  • Instant digital download — available immediately after purchase
  • High-resolution PDF format, optimised for screen and print
  • Organised folder hierarchy by variant and document type
  • Compatible with all PDF readers on desktop, tablet, and mobile
  • Free lifetime updates — all future additions delivered automatically

Further Reading

For a comprehensive history of the BV 222 Wiking — from its Lufthansa origins to post-war Allied evaluation — visit our dedicated research article:
The Blohm & Voss BV 222 Wiking — History, Engineering & Legacy →

This digital compilation, structure, indexing and presentation are © Sicuro Publishing. Historical documents reproduced for research and archival reference. This collection is intended for historical research, restoration reference, and scholarly study. It does not constitute airworthiness documentation. All trade names and designations remain the property of their respective owners.
